Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge - Discontinued
PLEASE NOTE: THIS PRODUCT HAS BEEN DISCONTINUED – Please contact us if you would like a recommendation of a unit to replace this model.
Product Description
|
The Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge is a fixed velocity gauge making it an affordable handheld precision tool that requires no special training to operate. The Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge has two user programmable velocities and 8 pre-programmed velocities to measure the thickness of aluminium, steel, stainless steel, cast iron, plexiglass, PVC, polystyrene and polyurethane – making the CG20 an ideal model for the person who tests a few different materials regularly. This small, lightweight, water resistant unit is easy to use and designed for the harshest environments. Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge Advantages
|
Specifications
Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge – Specifications
| Model & Part Number | CG20 |
| Ultrasonic Corrosion Thickness Gauge | |
| Material thickness digits display | • |
| Measurement Mode | PE |
| Measurement Rate Manual | 4 readings per second |
| Measuring Range | 0.63 – 500mm |
| Measurement Accuracy | ±0.01mm |
| Measurement Resolution | 0.01mm |
| Velocity Calibration Range | 1250 – 10,000m/s |
| Additional Features | 2 user programmable & |
| 8 pre-calibrated velocities for: | |
| aluminium, cast iron, plexiglass, polystyrene, | |
| polyurethane, PVC, stainless steel & steel | |
| Transducer Probe Type | dual element |
| Transducer Frequency Range | 1 – 10MHz |
| V-path / dual path error correction | automatic |
| Probe zero | manual (via integrated probe disk) |
| Display | 12.7mm high digits |
| Units (selectable) | mm or inches |
| LED Backlight | on / off / auto |
| Repeatability / Stability Indicator | • |
| Battery Type | 2 x AA alkaline |
| Battery Life (approximate) | 200 hours |
| Low Battery Indicator | • |
| Battery Save Mode | auto |
| Operating Temperature | -30 to 50ºC |
| Size (w x h x d) | 63.5 x 114.3 x 31.5mm |
| Weight (including batteries) | 284g |
| Aluminium case design with | • |
| gasket sealed end caps, | |
| waterproof membrane keypad | |
| Transducer Connector Type | LEMO |
| RS232 Interface | for programming only |
Elcometer NDT CG20 Corrosion Ultrasonic Thickness Gauge Packing List:
- Elcometer NDT CG20Corrosion Ultrasonic Thickness Gauge
- Couplant
- Carry case
- User manual
- Test certificate
- 2 x AA batteries
- Software
- Transfer Cable
